by Shining 3D
Standard Warranty Extension
$1,649.00
Tri-mode industrial 3D scanning for portable, high-detail, and large-area workflows
The EinScan Rigil is Shining3D's most advanced portable 3D scanner, combining laser HD precision and IR Rapid speed in a single wireless-capable device. With a built-in 6.4" 2K AMOLED touchscreen, onboard compute, and dual battery system, the Rigil operates fully standalone in the field - no laptop required. From aerospace inspection to large-scale reverse engineering, it delivers metrology-grade results wherever the work takes you.
- Standalone and PC-connected workflow options.
- Built for both detailed and rapid scanning modes.
- Strong fit for reverse engineering, inspection, and mixed industrial use
Best For
- Mixed industrial workflows
- Reverse engineering of mechanical parts
- Teams needing both portability and deeper capability
- Buyers who want one scanner to serve multiple job types
Work/Scan Modes
Work Modes
- Wireless Standalone -fully self-contained operation with onboard CPU, RAM, and SSD
- PC-Wireless / PC-Wired-connect to a PC for extra computing resources
Scan Modes
- Laser HD -25+25 crossed blue laser lines for ultra-high accuracy detail capture
- IR Rapid -IR VCSEL for high-speed large-area scanning
Technical Specifications
- Light Source: Laser HD: 25+25 crossed blue laser lines | IR Rapid: 7 blue laser parallel lines + IR VCSEL
- Resolution: Laser HD: 0.05–10 mm | IR Rapid: 0.2–10 mm
- Scan Speed: 25+25 crossed blue lasers: 4,800,000 pts/s | 7 blue laser lines: 1,480,000 pts/s | IR Rapid: 16,000,000 pts/s
- Working Distance: Laser HD: 170–550 mm | IR Rapid: 160–1,500 mm
- Volumetric Accuracy: Laser HD: up to 0.04 + 0.06 mm/m | IR Rapid: up to 0.1 + 0.4 mm/m
- Alignment Modes: Laser HD: Global Markers / Markers / Features | IR Rapid: Global Markers / Markers / Features / Texture / Hybrid
- Camera Resolution: 3D: 2.3MP×2 + 1.3MP×2 | Texture: 5MP
- Laser Class: Laser HD: Class II | IR Rapid: N/A
- Output Formats: STL, OBJ, PLY, 3MF, ASC
